EURO 7.6 Standard Pneumatic Quick Couplings – 320 Series
The 320 Pneumatic quick couplings from the POOLKE 320 Series are designed for industrial compressed-air systems that require high flow performance, easy handling and broad European-profile interchangeability. With a 7.6 mm nominal flow diameter and flow capacity up to 2100 L/min, the series provides efficient air delivery for pneumatic tools, production equipment and factory air networks.
The 320 Series features an unbaffled poppet design that helps improve airflow while keeping connection force low. One-hand operation allows fast tool changes and convenient maintenance, while nickel-plated brass/steel sockets and hardened zinc-plated steel plugs provide dependable durability for frequent industrial use. Optional double shut-off configurations are also available for applications requiring valve closure on both sides after disconnection. With multiple threaded and hose connection options, the 320 Pneumatic quick couplings offer a versatile solution for European-style pneumatic installations.
Key Features
EURO 7.6 Profile Compatibility
Designed around the widely used European 7.6 mm profile for easy replacement and integration into existing compressed-air systems.
High Flow Performance
Provides airflow up to 2100 L/min, supporting pneumatic tools and industrial equipment with demanding air requirements.
Unbaffled Poppet Design
The optimized internal valve structure reduces unnecessary airflow restriction and supports efficient compressed-air delivery.
Low Connection Force
Designed to make repeated coupling easier while maintaining secure connection performance during operation.
One-Hand Operation
Quick one-hand connection and disconnection improve efficiency during tool changes and equipment servicing.
Optional Double Shut-Off
Double shut-off versions are available for applications requiring both coupling and plug to close automatically after disconnection.
Applications
The 320 Pneumatic quick couplings are suitable for:
- Pneumatic tools
- Industrial compressed-air networks
- Factory automation
- Assembly lines
- Air compressors
- Manufacturing machinery
Technical Overview
| Series | 320 | Socket Material | Nickel-Plated Brass / Steel |
| Type | EURO 7.6 Standard Pneumatic Quick Couplings | Plug Material | Hardened Zinc-Plated Steel |
| Nominal Flow Diameter | 7.6 mm | Operation | One-Hand Operated |
| Flow Capacity | 2100 L/min | Valve Option | Optional Double Shut-Off |
| Max. Working Pressure | 35 Bar | Temperature Range | -20°C to +100°C |
Interchangeability
Cross-reference examples include:
- Rectus 25KA / 26KA Series Type
- Legris 25 / 26 Series Type
- Tema 1600 Series Type
- Auto-Flo 24 Series Type
- Bosch Size 3 Type
- Parker RF-1/4 / PE / PEF52 Series Type
- CEJN 320 Series Type
